I will do pcb design for esp32 and esp8266 on easyeda and kicad

A: You will receive all necessary manufacturing-ready files, including Gerber files, schematics, BOM, layouts, and pick-and-place files. If needed, I can provide additional documentation based on your requirements.

A: I use industry-standard tools such as Allegro PCB Designer, Altium Designer, KiCAD, Eagle, Proteus, and EasyEDA, depending on the project's needs and your preference.

A: Yes, I can help with component selection, sourcing, and creating a Bill of Materials (BOM) to ensure all parts are readily available and cost-effective.

A: I do not directly manufacture PCBs, but I can guide you through the prototyping and manufacturing process and deliver files optimized for fabrication (DFM and DFA compliant).

Yes I do order PCBs from JLCPCB, PCBWAY, NEXTPCB, etc.

A: Yes, I have experience with high-frequency and RF PCB designs, and I can ensure proper impedance control, layout optimization, and other key considerations.

A: Delivery time depends on the complexity of the design. Simple designs can be completed in 2–3 days, while complex projects may take a week or more. Let’s discuss your project to provide an accurate timeline.

A: Absolutely! I specialize in designing single-layer, double-layer, and multi-layer PCBs to meet your project requirements.

A: Yes, I offer revisions to ensure your satisfaction. The number of revisions depends on the package you select, but I’m happy to discuss your feedback to make necessary adjustments.

A: Yes, I can sign a Non-Disclosure Agreement to ensure your project's confidentiality and security.
