Are you a UK Domestic Energy Assessor (DEA), Retrofit Surveyor, or Estate Agent struggling with drafting backlogs?
I specialize in converting site survey sketches into accurate, clean 2D floor plans using PlanUp and AutoCAD. My service is designed to save you 30 to 45 minutes per property survey, letting you focus on site visits while I handle the drafting.
What You Will Get:
- Complete 2D Layouts: Ground, First, Loft, Extensions, and Flat floor plans.
- RdSAP & EPC Data Set: Heat Loss Perimeter (HLP) calculations, Party Wall (PW) lengths, and floor area breakdowns.
- Schedules & Legends: Individual window/door metric area schedules and energy symbol legends (Boilers, TRVs, Meters, Lighting).
- Deliverables: Native .planup source files, high-resolution PDFs, and JPEGs.
Why Choose Me?
- UK RdSAP Standards: Drafted strictly following Elmhurst and PlanUp formatting rules.
- Fast Turnaround: 12 to 24-hour delivery to keep your workflow moving.
- Accuracy: Verified HLP and wall dimensions for smooth portal data entry.
Outsource your floor plan drafting today and clear your survey backlog! Send over a sketch to get started.
