Need precise CNC ready CAD designs that manufacturers can actually use? I create accurate mechanical CAD models and professional manufacturing drawings with tolerances, ensuring your parts are ready for machining.
What I do
- CNC machining CAD design
- Mechanical part modeling
- SolidWorks parametric design
- Manufacturing ready drawings
- Tolerances and dimensioning
- GD&T (Geometric Dimensioning & Tolerancing)
- STEP, IGES, STL file creation
- Technical drawing preparation
- Reverse engineering from sketches/photos
- Design for manufacturing (DFM)
- Assembly design and exploded views
- BOM (bill of materials) creation
- Sheet metal and machined part design
- Precision engineering modeling
What you get
- 3D CAD model (SolidWorks)
- STEP / IGES / STL files
- Manufacturing drawings (PDF)
- Accurate dimensions and tolerances
- Clean, editable parametric design
- Fast delivery and revisions
Send your sketches, dimensions, reference images, or requirements before ordering. Ill review your project and recommend the best package for your machining needs.
