I will design custom pcb penalization for fabrication and pcb assembly
Printed circuit board expert
I am a PCB Design Engineer with experience in designing high-quality printed circuit boards for consumer electronics, industrial automation, IoT, RF, medical, automotive, and marine applications. I cr...
About this Gig
Production Ready PCB Panelization for Manufacturing
Getting a PCB panel wrong can increase manufacturing cost, cause assembly problems, and delay production. I provide professional PCB panelization services to prepare your boards for smooth fabrication and SMT assembly.
Whether you need a single design or multiple boards in one panel, I will create a clean, efficient, and manufacturer-ready panel that meets your fabrication requirements.
What I Offer
- Custom PCB panelization
- SMT assembly panel layout
- V-score panel design
- Mouse bite (breakaway tab) panel
- Tooling holes
- Global and local fiducials
- Panel frame (rail) design
- Multiple PCB array layout
- Manufacturing-ready Gerber files
- Fast revisions and clear communication
Why Choose Me?
- Production-focused PCB panel designs
- Accurate and organized work
- Fast response and delivery
- Easy communication
- Reliable support
If you already have Gerber files or PCB design files, simply send them over and I'll prepare a professional panel ready for fabrication.
Message me before ordering if you have custom manufacturing requirements
Other Electronics Engineering Services I Offer
FAQ
What files do you need?
Gerber files, PCB design files (KiCad, Altium, EasyEDA, Eagle, etc.), or your manufacturer's panel requirements.
Can you follow my PCB manufacturer's rules?
Yes. I can create the panel according to your fabrication or assembly requirements.
Can you add V-score and mouse bites?
Yes. I can design panels using V-score, mouse bites, or both if required.
Will the panel be ready for SMT assembly?
Yes. I include features such as fiducials, tooling holes, rails, and proper spacing when needed.
Which PCB software do you support?
I work with Altium Designer, KiCad, EasyEDA, Eagle, and Gerber files from most PCB design software.
