I will create a 2d manufacturing drawing per asme
Bruno
About this gig
Need a 2D drawing your machine shop can actually build from, fast?
For over 3 years in aerospace manufacturing at Gulfstream, I created and reviewed complex multi-sheet drawings and released 500+ parts (machined, sheet metal, composite and assemblies) to production with zero findings. I know what a machinist or inspector needs to see, and what gets a part rejected.
WHAT I DELIVER:
- Fully dimensioned 2D drawings from your 3D model, sketch, or photo + measurements.
- GD&T per ASME Y14.5-2009/2018 (1994 for legacy): datums, tolerances, feature control frames.
- Section, detail and isometric views; multi-sheet as needed.
- Material, finish, heat/chemical treatment and general notes.
- Title block with your company logo, part number, revision and date.
DELIVERABLES:
- PDF + DWG/DXF, delivered in as little as 24 hours.
SOFTWARE & INPUTS:
- SolidWorks, CATIA, AutoCAD, FreeCAD. I accept STEP, IGES, native CAD, DWG/DXF, or sketches/photos with key dimensions. STL: message me first.
HOW I WORK:
- Tell me the process (CNC, sheet metal, 3D printing). Before finishing, I flag anything that will be hard or expensive to make.
Company drafting standard or close tolerances? Message me first.
Delivery style preference
Please inform the freelancer of any preferences or concerns regarding the use of AI tools in the completion and/or delivery of your order.
Get to know Bruno
Bruno
3D CAD design and 2D drafting
- FromMexico
- Member sinceAug 2025
Languages
English, Spanish
I'm an aerospace engineer with over 3 years of experience in a world-leading aerospace manufacturer like Gulfstream, where a wrong dimension grounds an aircraft. I bring that discipline to precise 3D CAD (CATIA, SolidWorks, AutoCAD, FreeCAD, etc.) and 2D drawings with rigorous GD&T per ASME Y14.5. Reverse engineering to rebuild an old paper drawing or a real part into an accurate, editable 3D model you can modify, re-manufacture, or document. Plus clear 3D work instructions. 500+ aerospace parts released to production.
FAQ
What do I need to send you?
Your 3D model (STEP, IGES or native CAD) is best. A sketch or photo works if it includes key dimensions. Also tell me the manufacturing process, material, finish and any critical features.
Can you use my company's drawing template and standards?
Yes. Send your title block, drafting standard, and process or finish codes, and I'll follow them exactly.
Which units and standards do you work with?
Inch or metric. GD&T per ASME Y14.5-2009/2018, and 1994 for legacy drawings. For ISO GPS, message me first.
Can I get the native CAD file?
Every package includes PDF + DWG/DXF. If you need the native file (SolidWorks, CATIA, FreeCAD), message me before ordering.
Can you design a part from scratch?
This gig covers drawings of existing parts or designs. For new design or reverse engineering, message me for a custom offer.
Will you sign an NDA? Can you work with ITAR parts?
Yes, I'm happy to sign an NDA. Please don't send ITAR or export-controlled data: Fiverr is not an approved platform for it.
What counts as a revision?
Changes to the drawing as ordered: dimensions, notes, views, title block. Changing the part design or adding parts is a new order or an extra.
What if my part is not manufacturable?
I'll flag features that are hard or expensive to make (tolerances, radii, hole depths, bend reliefs) and suggest alternatives before finishing.
