I will design retaining wall and cmu block structural drawings

STOP risking structural failures with generic drawings. Get professional, permit-ready structural engineering blueprints designed to withstand precise lateral earth pressures, surcharge loads, and hydrostatic forces.

I am a professional structural engineer delivering code-compliant retaining wall and CMU block structural engineering drawings for municipal approval, residential developments, and commercial projects.

Engineering Expertise Offered:

Cantilever & Gravity Walls: Reinforced concrete and CMU block wall design.

Rigid & Flexible Systems: Segmental retaining walls (SRW) and gravity stone systems.

Structural Drafting: High-precision CAD engineering drawings with detailed rebar schedules.

Connection Details: Footing-to-stem reinforcement, construction joints, and weep hole drainage layouts.

Engineering Calculations: Sliding, overturning, and bearing capacity safety factor checks.

Design Codes Handled:

IBC / IRC (International Building / Residential Code)

ACI 530 / TMS 402 (Masonry Structures)

ACI 318 (Structural Concrete)

What You Get:

Complete high-resolution PDF sets

Native DWG/CAD source files (Gig extra/Standard+)

Professional calculation report
