Need accurate sheet metal designs ready for fabrication and laser cutting?
I will design professional sheet metal brackets, plates, supports, enclosures, and custom components based on your sketches, dimensions, images, samples, or existing CAD files.
My services include:
- Sheet metal bracket design
- DXF flat patterns
- Laser cutting files
- Bend lines and allowances
- 2D manufacturing drawings
- 3D CAD models
- Precise holes, dimensions, and material thickness
I create clean, practical, and manufacturing-ready designs according to your specifications. Whether you need a simple bracket or a complex sheet metal component, I will ensure the design is accurate and suitable for fabrication.
You can provide sketches, photos, measurements, PDFs, or existing CAD models. I can deliver files such as DXF, STEP, and PDF based on your project requirements.
Please contact me before placing an order if you have specific material, thickness, bending, tolerance, or laser-cutting requirements. Im ready to turn your idea into a precise, fabrication-ready sheet metal design.
Delivery style preference
Please inform the freelancer of any preferences or concerns regarding the use of AI tools in the completion and/or delivery of your order.
Get to know ASHER CAD
ASHER CAD
3D CAD Designer, Reverse Engineering Specialist
- FromNigeria
- Member sinceAug 2026
- Avg. response time4 hours
Languages
English, French, German
I’m Curt, a 3D CAD designer specializing in reverse engineering, mesh-to-solid conversion, parametric modeling, and custom replacement parts. I create accurate, editable CAD models from STL files, meshes, scans, measurements, drawings, and physical-part references for prototyping, 3D printing, and manufacturing.
FAQ
What do you need from me to start the project?
You can provide sketches, dimensions, photos, measurements, PDF drawings, samples, or existing CAD files. The more accurate the information, the more precise the final design will be.
Can you create DXF files for laser cutting?
Yes. I can create accurate DXF flat patterns prepared for laser cutting, including the required geometry, holes, cutouts, and bend information based on your specifications.
Can you design custom sheet metal brackets?
Yes. I can design custom brackets, plates, supports, enclosures, and other sheet metal components based on your requirements, dimensions, or reference materials.
What file formats can you deliver?
Depending on your project, I can provide DXF flat patterns, STEP 3D models, and PDF 2D manufacturing drawings. Other formats can also be discussed before ordering.
Can you work with specific material thickness and bending requirements?
Yes. I can design according to your specified material, thickness, bend dimensions, bend allowances, hole sizes, and other manufacturing requirements. Please provide these details when available.
