Are you looking for professional lighting layouts, switching plans, and electrical installation schematics for your building project?


I will create detailed lighting design drawings for residential, commercial, and industrial buildings. My services include lighting fixture layouts, switch locations, switching control plans, lighting circuit diagrams, installation schematics, fixture schedules, and coordinated electrical drawings.


Using AutoCAD and Revit MEP, I prepare clear, organized lighting plans tailored to your project requirements. I can also assist with emergency lighting layouts, lighting circuit identification, fixture specifications, and electrical documentation to support construction and installation.


What you will receive:

Detailed lighting layouts and fixture placement

Switching plans and control arrangements

Lighting installation schematics and circuit diagrams

Lighting fixture schedules and legends

Professional AutoCAD and Revit drawings

Timely delivery and clear communication



Contact me today with your architectural floor plans and project requirements to discuss your lighting design needs before placing your order!
