I will do rf pcb design with antenna layout, high speed routing, controlled impedance
IoT PCB Designer, Wireless PCB Expert, ESP32, WiFi, BLE, GSM, LTE, NB IoT CAT M1
About this Gig
When an RF or high-speed PCB isn't laid out correctly, the problem isn't always obvious on the screen. A board can look clean and still have routing, impedance, return-path, or placement issues that affect signal performance.
That's where I come in.
I design RF, antenna, high-speed, and multilayer PCBs around the electrical requirements of the circuitnot simply by connecting components and filling the board.
I work with:
Controlled impedance
RF routing
High-speed signals
Differential pairs
Length matching
Transmission lines
Grounding
Shielding, and signal-integrity considerations
For wireless designs, I can work with WiFi, BLE/Bluetooth, GPS/GNSS, LTE, GSM, LoRa, and other RF circuits according to the project requirements.
Software Used:
- Altium Designer
- KiCad
- Cadence OrCAD
- EasyEDA and many more.....
Deliverables Includes
- Gerber files
- NC Drill
- BOM
- PCB/schematic source files
- PDF documentation
- 3D STEP files
- And many more based on your requirements
If you have an RF, antenna, high-speed, or multilayer PCB that needs to be designed, redesigned, or prepared for fabrication, send me what you have and let's build it around the actual requirements of the board before placing an order
