I will design rf pcb antenna iot esp32 high speed pcb and schematic
About this Gig
Need a professional RF PCB, high-speed PCB, IoT, or embedded hardware design expert? You're in the right place.
I provide complete schematic design, PCB layout, and manufacturing-ready hardware solutions for wireless, RF, microwave, IoT, and embedded systems. I have extensive experience designing boards based on SX1276, SX1278, LR1120, MC60, A9G, SIM800, SIM7000, SIM868, ESP32, STM32, Arduino, GPS, GSM, LTE, LoRa, WiFi, and BLE technologies.
Services Include:
- RF PCB
- High-Speed PCB
- Antenna Layout Optimization
- IoT Hardware Development
- Schematic Capture & Circuit
- Multi-Layer PCB Routing
- Controlled Impedance Routing
- Signal & Power Integrity Optimization
- EMI/EMC Reduction
- PCB Review & Improvement
- Manufacturing Support
Software:
Altium Designer, KiCad, EasyEDA, Eagle, Cadence OrCAD, CST Studio, ADS, HFSS
Deliverables:
- Schematic Source Files
- PCB Layout Files
- Gerber & Drill Files
- BOM
- Pick & Place Files
- 3D PCB Model (STEP)
- Assembly Documentation
Applications:
IoT Devices, Wireless Products, GPS Trackers, LoRa Systems, RF Modules, Sensor Boards, Power Electronics, Embedded Systems, Industrial Electronics, and Custom Hardware Projects.
Bring your requirement and let bring it to life!
FAQ
What information do you need before starting my project?
provide your project requirements, schematic (if available), preferred PCB dimensions, layer count, components list, and any manufacturing requirements
Which software do you use for PCB design?
I work with Altium Designer, KiCad, EasyEDA, Eagle, Cadence OrCAD, CST Studio, ADS, and HFSS depending on project requirements.
What deliverables will I receive?
You will receive schematic files, PCB layout files, Gerber files, drill files, BOM, Pick & Place files, 3D PCB models, and manufacturing-ready documentation.
