I will review and make correction to your pcb design before manufacturing
PCB DESIGN LAYOUT ENGINEER
Level 1
Has met certain performance criteria and shows strong potential in the marketplace.
About this Gig
NEED YOUR PCB DESIGN REVIEWED OR CORRECTED AT AN AFFORDABLE RATE?
I'll professionally review and optimize your PCB design for manufacturing so its fully production-ready, cost-effective, and free from costly design flaws before it ever reaches the fabrication.
With expertise in KiCad, Altium Designer,EasyEDA I will thoroughly check your schematic and PCB layout for:
- Trace Width & Spacing Correct impedance and clearance for your signal requirements.
- Pads, Vias & Drill Sizes Ensuring manufacturability and proper component fit.
- Silkscreen & Layer Alignment Clean, accurate markings for easy assembly.
- Ground Planes & Thermal Relief Optimized for stability and heat management.
- Power Routing Efficient, noise-free power delivery.
- BOM & Placement Optimization Reduce cost and improve assembly efficiency.
- Gerber File Validation Final checks before sending to your manufacturer.
I WILL ALSO PROVIDE SUPPORT IN TERMS OF FINDING THE MOST SUITABLE MANUFACTURER FOR YOUR PCB
Lets make your PCB production-ready.
File format:
Gerber
•
STEP
•
SCH
•
3DS
•
Software:
Altium Designer
•
EasyEDA
•
KiCad
•
AutoCAD
Interface:
HDMI
•
I2S
•
UART
•
USB
•
SPI
•
I2C
•
Wi-Fi
•
BLE
•
BT
•
GSM/GPRS
My Portfolio
FAQ
Can you fix the issues found?
Yes, I can fix errors and optimize the design if requested.
Will I get a review report?
Yes, I provide a clear report with identified issues and recommendations.
Which PCB tools do you use?
I specialize in Kicad,EasyEDA and Altium Designer
What do you check in the PCB review?
I check for DFM issues, trace width, spacing, vias, and Gerber file accuracy.
