I will rf pcb layout with controlled impedance for wifi, bluetooth, lora and iot device

HELLO DEAR,

WELCOME TO MY SERVICE,

Looking for a reliable RF PCB designer for your wireless project? You're in the right place.

I specialize in designing high quality RF PCB layouts with controlled impedance for WiFi, Bluetooth (BLE), LoRa, and IoT devices. My des igns focus on signal integrity, RF performance, manufacturability, and industry best practices to help bring your product from concept to production.

What I can deliver:

RF PCB layout des ign

Controlled impedance routing

Component placement optimization

Ground plane and RF routing optimization

Design Rule Check DRC

Gerber files for manufacturing

BOM Bill of Materials

Pick and Place files

Source design files if requested

Technical support during fabrication

I work with professional PCB des ign tools and follow best practices to ensure reliable, production ready.

Please contact me before placing an order so we can discuss your project requirements and choose the best package for your needs.

I look forward to helping you build your next RF and IoT product!
