I will redraw your supplied sketch, PDF, image, or existing floor plan into a clear 2D drawing based on the available references and measurements.

This service is suitable for homeowners, remodelers, contractors, real estate professionals, and property managers who need an existing layout documented digitally.

Depending on your package, deliverables can include:

2D floor plan redraw

Walls, doors, and windows

Room names and labels

Dimensions from supplied measurements

PDF or image output

Editable AutoCAD DWG file in applicable packages

To get started, send your existing drawing, available dimensions, preferred output format, and any specific drafting instructions.

Please contact me before ordering if the project involves multiple floors, missing dimensions, complex layouts, or substantial changes.
