I will design dry dock and marine structural engineering drawings

Do you need engineered drawings for a dry dock, boatyard, marina structure, or waterfront support system? I provide marine and coastal structural engineering from floating and fixed docks to dry dock support cradles, bulkheads, and pier foundations built to withstand real marine loading conditions, not adapted from generic land-based structural templates.

What I deliver:

• Structural analysis for dry dock support cradles, keel blocks, and vessel weight distribution
• Fixed pier, pile, and bulkhead design with wave, current, and tidal load considerations
• Floating dock structural and buoyancy calculations
• Connection, anchorage, and mooring hardware detailing
• Drawings coordinated to ASCE 61 (Seismic Design of Piers and Wharves) and applicable local/coastal building codes
• Permit-ready PDF drawing sets, with PE stamp available where licensed

Ideal for: marina operators, boatyards, shipwrights, waterfront property owners, and marine contractors who need drawings a harbor authority or building department will actually accept not a generic dock template.

Message me with your vessel weight/dimensions (for dry dock work) or site conditions and structure type (for docks/piers) before ordering
