I will make pcb design pcb layout and circuit schematic
About this Gig
As a seasoned Electronics and Electrical Design Engineer, I offer exceptional PCB design services tailored to your specific needs. With expertise in embedded systems, product prototyping, PCB layouts, and circuit schematics, I excel in creating professional PCB layouts for microcontrollers, general electronics, and RF designs with impedance-controlled routing.
Over the past 5 years, I have mastered popular PCB design software, ensuring top-notch results. Even if you only have a project concept, I can develop a comprehensive schematic and design the PCB to match your specifications.
My services include:
- Circuit Schematic
- Gerber File
- Bill of Materials (BOM)
- Pick and Place File
- Assembly Layout
- 3D Model
Software Proficiency:
- EasyEDA
- Autodesk EAGLE
- Fusion 360
- KiCad EDA
Specifications:
- 2-6 layers
- THT & SMT components
- Rigid-flex PCB
- Any dimension, shape, and size
Every project is unique, so the provided packages are estimates based on general requirements. Please feel free to contact me for a personalized quote.
Let's bring your ideas to life with precision and innovation.
File format:
Gerber
•
STEP
•
BRD
•
SCH
•
Software:
Eagle CAD
•
EasyEDA
•
Fusion 360
•
KiCad
•
AutoCAD
•
Arduino
Interface:
HDMI
•
I2S
•
UART
•
USB
•
SPI
•
SDIO
•
Wi-Fi
•
BLE
•
BT
•
GSM/GPRS
•
LTE
FAQ
What files do you need to design the PCB?
If you already have the schematic or circuit diagram ready with you, then you can send it to me to get started. It will be helpful if you have the source file otherwise you can also send me the circuit diagram in PDF or Image format and I can make the schematic to design the PCB.
I have a circuit design, can you convert it to PCB layout
Yes, I can design the PCB layout for your project from the schematic you have provided
I have a project idea, can you create the schematic and PCB design for it?
Yes, I can design the schematic and the PCB design from scratch. All I need the functional principal and the intended use of the PCB and I will source the components, design the schematic and the PCB layout for your project.
What specifications do you need to design the PCB?
Please mention the shape of the PCB and the required dimension. Most of the general purpose PCB is either rectangular or round shaped but if it's a custom shaped and there are mounting holes and cutouts mention that as well. And also the components are surface mount (SMT) or through hole (THT) type.
What files you will provide me and what do I do with that?
To manufacture the PCB all you need is the GERBER file, a zip file that you can send to any PCB manufacturer to fabricate the PCB and the schematic to hand solder the components. If you want to assemble it professionally, you will additionally need Bill of materials (BOM) and Centroid file (PNP).
Can you help me sourcing the components and place the PCBA order?
At this critical time of component shortage it is essential to check the whether the used parts are and will be in stock. So I always ensure that during the design phrase.
