Need an as-built drawing from a sketch, PDF, or old blueprint?
I redraw it into a clean, editable AutoCAD DWG at correct scale.
WHAT YOU GET:
- As built floor plans and site plans of existing houses and buildings
- 2D floor plan tracing from sketches, PDFs, images, or redlines
- PDF to DWG conversion with organized layers
- Dimensions, annotations, and title block on Standard and Premium
- Elevations on request
WHY CLIENTS COME BACK:
12+ years as a Civil engineer and AutoCAD drafter. I read drawings the way a builder does, so walls close, dimensions add up, and layers are named the way your team expects. Electrical and plumbing layers available, which most tracing sellers cannot offer.
HOW IT WORKS:
1. Send your sketch, PDF, or site photos
2. I confirm scale, units, and scope
3. You receive DWG + PDF for review
Packages are set by area and floors, not file type. Basic covers 1 floor up to
1000 sq ft, Premium up to 3 floors and 6000 sq ft. All packages include the
editable DWG.
Drawings are formatted for submission. Sealing is handled by your local licensed
professional.
Larger project or multiple buildings?
Message me for a custom offer.
Service verification and delivery style preference
Fiverr does not screen freelancers in this category. Please verify qualifications and discuss requirements with the freelancer before ordering, including any preferences regarding the use of AI tools.
Get to know Kamrul Shohag
Kamrul Shohag
Construction CAD Drafting Specialist
Level 2
- FromBangladesh
- Member sinceSep 2016
- Avg. response time1 hour
- Last deliveryabout 22 hours
Languages
English
Helping U.S. contractors, architects, engineers, and fabrication shops turn sketches, PDFs, and markups into accurate, construction-ready CAD drawings. Backed by 13+ years of experience and over 1,500 CAD drafting projects, I specialize in floor plans, permit drawing support, plumbing layouts, PDF to AutoCAD conversion, and production-ready DXF files for CNC, laser, plasma, and waterjet cutting.
My Portfolio
Other Architecture & Interior Design Services I Offer
FAQ
What do you need to start my as built drawing?
A hand sketch, PDF, JPG, scanned floor plan, or site photos all work. Field measurements help me match the existing building exactly. If you have an older DWG file, send that as well.
Do I get an editable AutoCAD DWG file?
Yes, in every package including Basic. You receive the native AutoCAD DWG plus a PDF, so PDF to DWG conversion and full as-built drafting come in one delivery. Just tell me your AutoCAD version.
Which package fits my project?
Packages are set by area and floors, not file type. Basic covers 1 floor up to 1000 sq ft, Standard up to 2500 sq ft with full dimensions, Premium up to 3 floors and 6000 sq ft. Message me if you are unsure.
Can you redraw a floor plan from a sketch that is not to scale?
Yes, tracing from a rough sketch is my most common request. One known dimension is enough to scale the whole floor plan accurately. If nothing is known, I will list my assumptions before starting.
Can you produce as-built drawings of an existing house or building?
Yes. Send your measured sketch, site survey notes, photos, or old blueprints and I will produce clean as built drawings that reflect the property as it stands today.
Can you follow our company CAD standard?
Yes. Send your template, title block, or layer naming standard and I will build the DWG inside it rather than my own setup.
Can you add electrical or plumbing layers?
Yes. I am a plumbing engineer with over 12 years of drafting experience, so MEP layers are available. Share the reference sheets and I will quote it.
Do you provide elevations or sections?
Elevations are available as an extra alongside your floor plan. Send me the reference photos or drawings and I will confirm scope and price before you order.
