I will do pcb design layout, electrical, electronic engineering, matlab simulink
A Professional PCB Designer
About this Gig
Need a manufacturing-ready PCB? You're in the right place.
I'm a certfied electronics engineer delivering full-service PCB design from blank page to Gerbers your fab house accepts on the first try.
What you get:
- Schematic capture with proper nets, decoupling, and design-for-manufacturing rules
- Multi-layer PCB layout with clean routing, controlled impedance where needed, and solid ground planes
- Gerbers, drill files, BOM, and CPL ready for JLCPCB, PCBWay, or your preferred fab
- 3D render and DRC/ERC-clean project files
Specializations:
- MCU boards (ESP32, ESP32-S3, RP2040, STM32)
- Power electronics and BMS (multi-cell, balancing, protection)
- Mixed-signal and moderate high-speed (USB, RMII, differential pairs)
- Wearables and compact handhelds where space is tight
Tools: KiCad, Altium Designer, OrCAD your choice.
Why me: Every board I deliver goes through a documented review: schematic audit, DRC pass, BOM/CPL cross-check against fab capabilities. No surprises at assembly.
Message me with your requirements rough specs, sketches, or existing files all work and I'll send back a scope and timeline within hours.
FAQ
What do you need to get started?
A brief: what the board does, key components (MCU, sensors, connectors), size/form-factor constraints, target fab house, and any reference designs. A rough block diagram helps.
Do you sign NDAs?
Yes, happy to sign before any files are exchanged.
Do you work from an existing schematic?
Yes. Send your schematic (any format) and I'll do layout-only at a reduced rate, message me first.
Can you order the boards for me?
I provide fab-ready files optimized for JLCPCB and PCBWay.
What files do I receive?
Native project files (KiCad/Altium/OrCAD), Gerbers, drill files, BOM (CSV), CPL/pick-and-place (CSV), 3D STEP export, and a PDF schematic
