I will create precise, efficient loop cad designs for your underfloor heating projects
Underfloor Heating Loop CAD Design
Our expert team creates detailed Loop CAD designs tailored to your specific underfloor heating project requirements.
We leverage advanced technology and industry expertise to deliver precise and reli...
Level 1
Has met certain performance criteria and shows strong potential in the marketplace.
About this Gig
Are you looking for professional, accurate CAD layouts for underfloor heating (UFH) systems?
I offer tailored 2D designs for residential and commercial projects, ideal for installers, architects, and engineers.
With MaxHeatUFH standards, I provide:
- Precise UFH loop layouts with quick turnaround times
- Pipe length and manifold size calculations
- Zoning for optimised performance
- Scalable designs up to 10,000+ sq. ft.
- Delivery within 1-2 working days
Packages include:
Basic: Full loop design, 1 floor only, up to 100m2/ 1,000 sq. ft
Standard: Full loop design, 1 floor only, any m2 over 100m2/ 1,000 sq. ft
Premium: Full loop design, 2 floors or more, any m2
You'll receive a clear, installation-ready 2D PDF file.
Lets ensure your UFH system is efficient, reliable, and easy to install. Send your floor plan today and get started!
Project scale:
Building
Building type:
Residential
•
Commercial
•
Office & workspace
Material speciality:
Concrete
•
Wood
Delivery style preference
Please inform the freelancer of any preferences or concerns regarding the use of AI tools in the completion and/or delivery of your order.
My Portfolio
FAQ
What information do you need to get started?
To begin, I’ll need a floor plan (PDF, DWG, or image), estimated project size (in sq. ft or m²), room usage/zones, and any specific requirements like manifold location or pipe spacing preferences. The more details you provide, the better the result.
Do you include pipe length and manifold sizing in the design?
Yes. All quick, and full loop design packages include total pipe length required, manifold sizing, and zoning layouts. This information is provided along with the quick/ full CAD drawings for easy installation.
What is the difference between the Basic, Standard & Premium package?
Basic: Full loop design, 1 floor only, up to 100m2/ 1,000 sq. ft Standard: Full loop design, 1 floor only, any m2 over 100m2/ 1,000 sq. ft Premium: Full loop design, 2 floors or more, any m2
Can you work with metric or imperial units?
Absolutely. I can design in either metric (m², mm) or imperial (ft², inches) units based on your location or project preferences. However m², mm is preferred.
