I will do custom pcb design schematic pcb layout for esp32 iot usb hub circuit design
From Circuit Ideas To Working PCB USB and Embedded Hardware Expert
I am a PCB and Embedded Hardware Engineer specializing in schematic design, circuit design, and multi layer PCB layout using Altium, KiCad, Eagle, and EasyEDA. I design STM32/ESP32 based systems, USB/...
About this Gig
Need a reliable, production ready PCB that actually works the first time?
I design custom PCBs from schematic capture to final layout engineered for precision, optimized for manufacturability, and built to meet your exact technical requirements.
Whether you're prototyping an ESP32 based IoT device, building a USB hub circuit, or need a multilayer PCB layout for a complex embedded system I've got the hardware expertise to bring your design to life.
What You Will Get
- ESP32 Custom Board Design
- IoT Sensor Node PCB
- USB Hub Circuit Design
- Wireless IoT Gateway Board
- Power Supply / PMU Board
- Motor Driver & Control Board
- USB Type-C PD Circuit Design
- Industrial Interface PCB
- Custom Arduino / Dev Board
- Schematic Capture & Gerber
Tech Stack &Tools
- Kicad
- Altium Designer
- Easyeda
- LTspice
- Esp32
- Stm32
- SMD/THT Components
- Buck/Boost Converters
- LDO Regulators
- UART
- I2C / SPI / USB 2.0 / USB 3.0
Deliverables,
- Schematic PDF + source file
- PCB layout source file
- Gerber + drill files (fab-ready)
- Bill of Materials (BOM)
- 3D PCB render
Ready to move from idea to board? Drop me your requirements block diagram, spec sheet, reference design, or just a concept and let's build something that works.
FAQ
Which EDA tools do you use for PCB design?
I work with KiCad, Altium Designer, and EasyEDA depending on your preference. Final deliverables are always tool agnostic Gerber, BOM, and PDF outputs work with any fab house.
Can you design a PCB for my ESP32 project from scratch?
Yes. I handle the full design cycle ESP32 schematic capture, power regulation, USB to serial bridge, antenna placement, and DRC verified PCB layout ready for fabrication.
Will the Gerber files be ready for JLCPCB or PCBWay?
Absolutely. All fabrication outputs Gerber, Excellon drill files, Pick & Place, and BOM are formatted and verified for JLCPCB, PCBWay, OSHPark, and most standard fab houses.
Can you redesign or reverse engineer an existing PCB?
Yes. Share clear images or the original files and I'll recreate, optimize, or improve the layout cleaner routing, better component placement, and updated design rules.
How do you handle high speed signals like USB differential pairs?
All high speed traces are routed with length matching, controlled impedance, and proper ground referencing. ESD protection and decoupling are standard on every USB design.
