Are you trying to move a messy breadboard prototype with sensors hanging off it into a commercial IoT product?
I engineer high-efficiency, multi-sensor IoT edge nodes from scratch. Whether you need a smart agriculture monitoring station, an industrial asset tracker, or a home automation device, I consolidate your microcontrollers (ESP32, STM32, Arduino) and sensor systems onto a single, rock-solid, multi-layer circuit board.
What I Build Into Your Custom IoT Node:
Sensor Integration: Flawless layout mapping for I2C, SPI, and Analog sensors (temperature, humidity, IMUs, gas, light).
Robust Power Paths: Designing broad power systems that cleanly handle solar inputs, battery backup lines, or wide industrial DC inputs (9V-24V).
Communication Peripherals: Onboard routing for SD cards, hardware UART debug ports, status LEDs, and physical user controls.
Industrial DFM Compliance: Optimized for low assembly reject rates and clean part layouts.
What You Will Receive:
Fully detailed circuit schematics (PDF + Native source).
2-Layer or 4-Layer production-ready Gerber packages.
Fully mapped Bill of Materials (BOM) linked directly to LCSC, JLCPCB, or DigiKey stock.
Specialization:
Circuit design
•
Schematics
•
Layout
•
Gerber
File format:
Gerber
•
STEP
Software:
Altium Designer
•
Eagle CAD
•
EasyEDA
•
KiCad
•
CircuitMaker
Interface:
I2S
•
UART
•
SPI
•
I2C
•
SDIO
•
Ethernet
FAQ
Which controller should I pick: ESP32 or STM32?
If your IoT node requires built-in Wi-Fi and Bluetooth right out of the box, the ESP32 is best. If your node needs heavy mathematical processing, ultra-low battery sleep states, or complex industrial bus lines (like CAN), the STM32 is preferred.
Do you write the firmware code for the sensors too?
This gig focuses purely on the hardware blueprint and PCB development. However, I can write basic test firmware as a custom order gig add-on.
