Need a professional injection molded electronics housing designed for manufacturing?
I will create a clean, production-ready plastic enclosure for your PCB, IoT device, sensor, consumer electronics, or embedded product using SolidWorks and DFM principles.
I focus on practical enclosure engineering so your design is not only attractive, but also suitable for injection molding, assembly, prototyping, and factory production.
Services I offer:
- Injection molded electronics housing
- Plastic enclosure CAD design
- PCB mounting bosses and supports
- Snap fit and screw fastening features
- Ribs, fillets and draft angles
- Uniform wall thickness optimization
- Connector, button and port openings
- Internal component layout
- Parting line consideration
- DFM review and design optimization
- STEP, SLDPRT and STL files
- 2D production drawings
- Assembly ready CAD files
Send your PCB/STEP file, dimensions, component layout, preferred material, and manufacturing requirements before ordering.
Lets turn your electronics concept into a clean, factory-ready enclosure.
