I will create 3d cad model for cnc machine, reverse engineering dfm parts and 3d print

Need an accurate 3D CAD model for CNC machining, reverse engineering, DFM or 3D printing?

I create professional CAD models from technical drawings, sketches, dimensions, photos, measurements, PDFs, physical part references or existing CAD files. This Gig is suitable for replacement components, discontinued parts, prototypes, CNC machined parts, functional 3D prints and manufacturing focused designs.

What I Can Design;

• Reverse engineered components
• CNC machine parts
• Replacement & replica parts
• DFM focused components
• 3D printable mechanical parts
• Prototypes & functional parts
• Housings, brackets & covers
• Adapters, mounts & custom parts
• Existing part CAD reconstruction

For reverse engineering, I can use your available measurements, photographs and reference information to recreate the component as accurately as the supplied information allows.

What You Receive;

• Clean 3D CAD geometry
• Accurate dimensions
• Manufacturing focused features
• Holes, fillets, chamfers and clearances
• 3D printing friendly geometry where required
• Technical drawings when included
• Editable CAD source files when included

File Formats

STEP, STP, STL, IGES, IGS, DXF, DWG, OBJ and CAD source files.

Message me first
