I will design a professional custom pcb layout and schematic in altium or kicad

I'm an electronics engineer, and I turn complex schematics into clean, DFM-ready PCBs using Altium Designer and KiCad. Whether you need a simple 2-layer board for a prototype, or you're dealing with a dense multi-layer mixed-signal layout, I can get your manufacturing files sorted out.

What I typically work on:

• High-Speed & Mixed-Signal: Controlled impedance, differential pairs, and keeping your data buses length-matched.
• Embedded Hardware: ARM layouts, microcontrollers, sensor nodes, and IoT interfaces.
• Power Boards: High-current switching regulators, gate drivers, and clean power distribution networks (PDN).
• DFM / Fab-Ready: I make sure clearances are right, custom footprints are accurate, and your Gerbers are 100% DRC-clean so the factory doesn't reject them.

What you get with every order: Every package automatically includes:

• Complete Fabrication Gerbers & NC Drill Files
• Pick & Place (CPL) files
• A real Bill of Materials (BOM) with active supplier parts
• 3D STEP files so you can check your enclosure fits

Just shoot me a quick message with your schematic or project idea before you hit order so we can make sure everything is good to go!
