I will provide professional 2d cad drafting and technical drawings remotely

P
peskid13
P
peskid13
Otumokpopermit
provide professional 2d cad drafting and technical drawings remotely
Full Screen
provide professional 2d cad drafting and technical drawings remotely

About this gig

Do you need precise, industry-standard 2D technical drawings or professional CAD drafting done quickly and accurately?


Whether you are an architect needing overflow drafting support, a manufacturer requiring detailed part assemblies, or a homeowner turning a hand sketch into a clean digital blueprint, I provide reliable, high-quality 2D CAD remote design support.


I leverage advanced CAD software to convert your concepts, images, markup notes, or legacy papers into structured, multi-layered digital documentation.


️ Technical Drafting Services Offered:

Architectural Layouts: Precision floor plans, sections, exterior elevations, and roof maps.

Structural & Civil Layouts: Foundation outlines, framing distributions, and site coordinates.

Mechanical & Component Drafting: Manufacturing diagrams, parts detailing, and patent drawings.

Paper / PDF to CAD Conversion: Turning rough files into perfectly clean .DWG vector files.


What Every Project Delivery Includes:

Layer-Organized Source Files: Fully optimized .DWG or .DXF files mapped to standard line weights.

High-Resolution Scaled PDFs: Perfectly crisp formatting ready for direct physical printing or submittal

  • Project scale

    • Apartment

  • Software

    • Autodesk AutoCAD
    • ArchiCAD

  • Building type

    • Residential

  • Drawing type

    • Floor plan
Service verification and delivery style preference

Fiverr does not screen freelancers in this category. Please verify qualifications and discuss requirements with the freelancer before ordering, including any preferences regarding the use of AI tools.

Get to know Otumokpopermit

Otumokpopermit

Brigetyyperm

  • FromUnited States
  • Member sinceSep 2026

  • Languages

    English
Welcome! I am a professional Architectural Draftsman and CAD Designer specializing in code-compliant residential structures, interior remodels, and plan reviews.My core expertise lies in drafting permit-ready construction blueprints for detached garages, high-clearance RV garages, patio covers/pergolas, basement finishes, and attic-to-ADU conversions. I adapt my technical drawings to adhere strictly to regional building codes across California, Washington, Texas, Pennsylvania, and Colorado, ensuring smooth plan checks at the city or township level.
