I will design 3d sheet metal flat pattern for cnc laser cutting dxf file on solidworks
Salam moyo
About this gig
Stop wasting material on unproducible designs.
Are you tired of 3D models that look good on screen but fail on the shop floor? I am a professional mechanical designer specializing in high accuracy Sheet Metal Design and CNC Programming (G-Code).
With expertise in SolidWorks, Fusion 360, and Creo, I bridge the gap between a concept and a physical product. Whether you need a simple bracket or a complex industrial enclosure, I deliver files that are 100% ready for laser cutting bending, and milling.
What This Gig Offers:
- Precision Sheet Metal: Flat patterns with accurate K-factors and bend allowances.
- Advanced CNC Programming: Expert G-code generation via SolidCAM 3D Milling.
- Rapid Prototyping: Transitioning your ideas into STL/STEP for 3D printing or CNC.
- Industrial Optimization: I review your design to reduce material waste and machining time.
Deliverables Included:
- 3D Models: STEP, IGES, F3D, IPT, OBJ, STL.
- 2D/Cutting: DXF, DWG, SVG (Laser/Waterjet ready).
- Production: G-Codes for CNC machines.
Why Me?
Industrial Standard: I design for real-world manufacturing, not just visuals.
Software Versatility: Expert in SolidWorks, Fusion 360, and Creo.
MESSAGE ME NOW WITH THE DETAILS
Delivery style preference
Please inform the freelancer of any preferences or concerns regarding the use of AI tools in the completion and/or delivery of your order.
Get to know Salam moyo
Salam moyo
Mechanical Engineer and 3d Industrial Designer
- FromSpain
- Member sinceMar 2026
- Avg. response time1 day
Languages
English
Welcome!
I am a professional Industrial Designer and Mechanical Engineer with over 8 years of experience in transforming ideas into manufacturing-ready reality. I specialize in 3D Sheet Metal Design, Electronic Enclosures, and Mechanical Fabrication.
Having worked with global manufacturers and startups, I understand that precision is non-negotiable. My workflow utilizes SolidWorks and Fusion 360 to create high-fidelity models that reduce waste and assembly time. My goal is to bridge the gap between "concept" and "factory floor." Let's build something functional together.
My Portfolio
Other Industrial & Product Design Services I Offer
FAQ
What information do I need to provide to start?
To ensure 100% accuracy, please provide a rough sketch, a 2D PDF, or an image with dimensions. Crucially, let me know the material type and thickness so I can calculate the correct K-factor and bend allowance for your sheet metal parts.
Can you provide files ready for Laser Cutting or Waterjet?
Yes! I provide clean, high-quality DXF and SVG files specifically optimized for CNC laser, plasma, or waterjet cutting. These files are "ready-to-cut" with no double lines or open paths.
Do you provide the G-code for my CNC machine?
Absolutely. Using SolidCAM, I can generate the G-code tailored to your specific machine controller. Please specify if you need 2.5D or 3D milling paths when ordering the Premium package.
Which software do you use for designing?
I am an expert in SolidWorks, Autodesk Fusion 360, and PTC Creo. I can provide the native project files (F3D, IPT, or PRT) if you need to make future edits yourself.
Can you handle complex assemblies or just single parts?
I handle both! Whether it’s a simple bracket or a complex industrial enclosure with multiple interlocking sheet metal components, I ensure every part fits perfectly during assembly.
What file formats will I receive?
Depending on your needs, I deliver: 3D: STEP, IGES, STL, OBJ, F3D. 2D: DXF, DWG, PDF, SVG. Manufacturing: G-code (NC/TAP files).
Do you offer "Design for Manufacturing" (DFM) advice?
Yes. I don’t just draw; I engineer. If I see a feature in your design that is impossible to bend or too expensive to machine, I will suggest a cost-effective alternative before we finalize the model.
