I will do sheet metal drawings dxf files for laser cutting machine and flat pattern

Hi,

Welcome to my digital shop. Are you looking for a sheet metal Designer or drafter Then you will like to be the DXF file for the laser cutting machine, a Flat pattern for production, and design sheet metal products? If yes Congratulations you are in the right place.

A little about Myself;

I have 5 years plus experience with international companies or local companies, Building insulations, sheet metal structures, Mechanical sheet metal fabrication, sheet metal assemblies, and Product design. I will design sheet metal mechanical parts for your product in AutoCAD & Solidworks. One thing must remember is that I am new at Fiver, but I am not new in the field of Design.

I will provide the following services;

• 3D Visualization
• Flat patterns
• DFX file for the laser cutting machine
• Product design
• Prepare Production drawings
• Assemblies
• Rendering
• 2D Dwg files
• Concept development
• Calculations like bend deduction, tolerance, k factor, etc.

Disclaimer: This gig price is basic the cost will vary according to the job complexity.
