I will do rf design, rigid flex, allegro pcb, multilayer pcb for high speed circuit
PCB Design, Embedded Hardware, Electronics Engineer
About this Gig
I'm a Electronics and Embedded Hardware Design Engineer with 7+ years of experience specializing in RF des|gn, rigid flex, Allegro PCB, multilayer PCB, PCB des|gn for high speed circuits. I deliver reliable, manufacturing-ready PCB layouts optimized for signal integrity, controlled impedance, EMI performance, and production success.
Services I Offer
- RF PCB design, high-speed PCB layout
- Rigid flex, multilayer PCB des|gn
- Allegro PCB layout, schematic capture
- Controlled impedance routing
- Signal integrity, EMI-aware layout
- Custom footprint, library creation
- Gerber, BOM, Pick-and-Place generation
- DFM, DRC validation, production-ready files
Tools I Use
- Cadence Allegro, OrCAD, Altium Des|gner, KiCad, EasyEDA
File Formats Delivered
- Gerber RS-274X/X2, ODB++, BRD, SCH, BOM, Pick-and-Place, PDF, STEP
Why Work With Me?
- Unlimited Revisions
- Clean, optimized PCB layouts
- Manufacturing-ready deliverables
- High-speed routing expertise
- RF layout best practices
- Fast communication, on-time delivery
Please message me to discuss your project requirements before placing a direct order.
FAQ
What information do you need before starting my RF PCB design project?
Please message me before placing an order. To begin, I'll need your project requirements, schematic (if available), circuit description, board dimensions, layer requirements, component list (BOM), preferred PCB manufacturer, and any RF, impedance, or mechanical constraints.
Can you design high-speed multilayer PCBs with controlled impedance?
Yes. I design high-speed multilayer PCB layouts with controlled impedance routing, differential pair routing, optimized stack-ups, signal integrity considerations, and manufacturing-ready deliverables for reliable performance.
Do you provide rigid flex PCB design services?
Yes. I design rigid flex PCBs following industry best practices, including stack-up planning, bend region optimization, routing constraints, component placement, and fabrication-ready files.
Which PCB design software do you use?
I primarily use Cadence Allegro and OrCAD for professional PCB layout and RF design. I also work with Altium Designer, KiCad, and EasyEDA depending on your project requirements.
What files will I receive after project completion?
You'll receive Gerber files, ODB++, BOM, Pick-and-Place files, schematic PDFs, fabrication drawings, assembly drawings, and native design files when included in the selected package.
Can you modify or improve my existing PCB design?
Absolutely. I can redesign existing PCB layouts, optimize routing, improve signal integrity, convert boards to multilayer or rigid flex designs, update components, and prepare your design for manufacturing.
Can you design RF PCBs using Cadence Allegro?
Yes. I specialize in RF PCB design using Cadence Allegro, including multilayer routing, controlled impedance, RF component placement, grounding strategies, and production-ready manufacturing outputs.
