Do you need accurate Plant 3D models, P&ID drawings, or platform structural drawings?
I am a Plant 3D designer with over 10 years of experience in P&ID and platform/structural drawings.
I can help you turn sketches, PDFs, redlines, or old drawings into clean, professional CAD files.
What I can do for you:
- Plant 3D modeling (equipment, piping, supports, structures)
- P&ID drafting and updates
- Platform and structural steel drawings
- Piping layouts and isometric drawings
- Shop drawings and fabrication drawings
- As-built and redline updates
- PDF, sketch, or image to CAD conversion
- 2D drafting in AutoCAD
- Drawing cleanup, layer fixing, and title block setup
Why work with me:
- 10+ years of real plant design experience
- I understand P&ID symbols, piping standards, and structural details
- Clear communication and on-time delivery
- I review every drawing before delivery
What I need from you:
- Your sketch, PDF, photo, or existing drawing
- Project scope and drawing list
- Standards or symbols you want me to follow
- Deadline and file format (DWG, PDF, DXF)
Please message me before ordering so I can confirm the scope and give you the correct price.
