I will design kicad pcb layouts for sensors and embedded electronics
Survey GIS and CAD Automation Developer
About this Gig
Need a compact PCB for a sensor, Arduino interface or embedded electronics project? I design KiCad layouts from your checked schematic and agreed board requirements.
Services include:
- Single-layer and two-layer PCB layouts
- Sensor and microcontroller interface boards
- Component placement, routing and footprint checks
- Gerber and drill exports for your chosen manufacturer
- Design-rule checks and a 3D preview where included
Please contact me before ordering. Send your schematic, component part numbers, board dimensions, connector positions, layer count and manufacturer rules. I will confirm the component count, scope and deliverables.
Packages cover one agreed board design. Circuit development, firmware, physical prototypes, assembly and additional boards require a separate quote. The layout is checked against agreed design rules; electrical performance must be verified by prototype testing. Source files and output formats are agreed before work begins.
Specialization:
Circuit design
•
Schematics
•
Layout
File format:
Gerber
•
STEP
•
BRD
•
SCH
•
Software:
EasyEDA
•
Matlab
•
Proteus
•
AutoCAD
•
Arduino
•
CircuitMaker
My Portfolio
Other Electronics Engineering Services I Offer
FAQ
What should I send before ordering?
Send your checked schematic, component part numbers, board size, layer count, connector positions and manufacturer rules. I will confirm feasibility and the exact deliverables before you order.
Does this include manufacturing or physical testing?
These packages cover digital PCB layout work. Fabrication, assembly, shipping, firmware and physical testing are not included. Prototype testing is needed to verify electrical performance.
