I will transform your ideas into high quality electrical circuits
I am an electrical engineer specialized in PCB design and circuit engineering. I am passionate about innovation and thrive on solving the engineering challenges faced by clients. I am known for my str...
About this Gig
I offer professional PCB design and detailed schematic creation services tailored to your project needs. With over 8 years of experience in electrical engineering, I will transform your ideas into precise and functional electrical circuits. My services include:
- Custom PCB Design: Using Altium Designer, I will create high-quality PCB layouts that meet your specifications.
- Detailed Schematics: I provide comprehensive and accurate schematics to ensure your project is well-documented and easy to understand.
- Project Consultation: I will collaborate with you to refine and enhance your ideas, ensuring optimal functionality and performance.
- Component Documentation: Receive detailed documentation explaining the functionality of each component in your design, aiding in the assembly and troubleshooting process.
Lets bring your electronic projects to life with precision and expertise.
Specialization:
Circuit design
•
Schematics
•
Layout
•
Footprint
•
Gerber
File format:
Gerber
•
STEP
•
SCH
•
•
Other
Software:
Altium Designer
•
KiCad
•
NI Multisim
•
Tina Ti
Interface:
HDMI
•
I2S
•
TDM
•
UART
•
USB
•
SPI
•
I2C
•
SDIO
•
PCIe
•
Wi-Fi
•
BLE
•
BT
FAQ
What information do you need from me to start the project?
To get started, I need a detailed description of your project, including any sketches, diagrams, or reference materials you have. Please also provide specific requirements such as dimensions, components, and any design constraints. The more detailed your information, the better the design.
Can you help me with component selection?
Yes, I can assist with selecting the appropriate components for your project. I will recommend components based on your requirements and ensure they are compatible with your design. If you have preferred components, please let me know.
How do you ensure the quality and accuracy of the design?
I use professional software like Altium Designer to create precise and reliable designs. Each design undergoes a thorough review process, including simulations and design rule checks, to ensure it meets your specifications and industry standards.
What is the typical turnaround time for a project?
The turnaround time depends on the complexity and scope of your project. Typically, a simple PCB design can take 3-5 days, while more complex projects may take 1-2 weeks. I will provide a detailed timeline once I have all the necessary information about your project.
Do you offer revisions if I need changes to the design?
Yes, I offer revisions to ensure the design meets your expectations. The number of revisions included will depend on the package you choose. Additional revisions can be provided at an agreed-upon rate. My goal is to ensure you are completely satisfied with the final product.
Can you provide a 3D model of the PCB?
es, I can provide a 3D model of the PCB upon request. This helps you visualize the final product and ensures that all components fit correctly within your design constraints. Please specify if you need this service when placing your order.
What formats will the final files be delivered in?
The final files will be delivered in industry-standard formats such as Gerber files for PCB manufacturing, BOM (Bill of Materials) for component sourcing, and schematic files. If you need any specific formats, please let me know in advance.
Do you provide support after the project is completed?
Yes, I offer support for a limited period after the project is completed to address any issues or questions you may have. If you encounter any problems with the design or need further assistance, feel free to reach out.
Can you help with the manufacturing process?
While I specialize in design, I can assist with the initial steps of the manufacturing process by providing detailed files and documentation. If you need further help, I can recommend reliable PCB manufacturers and guide you through the process.
What if I need a completely custom design that isn't covered in your packages?
If you have a unique or highly specialized project, please contact me directly to discuss the details. I am flexible and can create a custom offer tailored to your specific needs and requirements.
