I will reverse engineer your pcb and deliver fabrication files
Financial Modeling and Forecasting Expert
About this Gig
Professional Rephrased Version:
I provide professional PCB reverse engineering services to accurately reconstruct your circuit design from existing PCBs, images, or documentation. Using high-quality PCB images or physical boards, I will extract the schematic, generate manufacturing-ready Gerber files, prepare a detailed Bill of Materials (BOM), and deliver organized, editable source files.
Whether your project involves a single-layer, double-layer, or complex multi-layer PCB, you will receive precise and well-documented design files suitable for manufacturing, product improvement, maintenance, or further development.
Specialization:
Circuit design
•
Schematics
•
Layout
•
Footprint
File format:
STEP
•
Software:
Altium Designer
•
EasyEDA
Interface:
I2S
•
USB
•
SPI
•
I2C
FAQ
What do you need to start the PCB reverse engineering process?
I can work with high-resolution PCB images, scanned board images, Gerber files, PDFs, or a physical PCB. The more information provided, the more accurate the reconstruction will be.
Can you reverse engineer both simple and complex PCBs?
Yes. I can handle single-layer, double-layer, and multi-layer PCB designs, depending on the complexity and available reference materials.
What files will I receive upon completion?
Deliverables may include schematic files, PCB layout files, Gerber files, drill files, Bill of Materials (BOM), and other fabrication-ready documentation as required.
Which PCB design software do you use?
I work with industry-standard tools such as KiCad, Altium Designer, EasyEDA, and Eagle, depending on project requirements.
