I will design rf pcb, high frequency pcb, antenna and impedance controlled pcb
Mechanical Design Engineer, 3D CAD Modeling, and Product Design
Level 1
Has met certain performance criteria and shows strong potential in the marketplace.
Highly Responsive
Known for exceptionally quick replies
About this Gig
Are you looking for a professional RF PCB specialist for a reliable, high performance electronic product? I provide high frequency PCB layout and RF engineering services for prototypes, IoT devices, wireless products, and production ready electronics.
My RF PCB services include:
RF PCB layout and high frequency routing
RF circuit schematics
Antenna integration and PCB antenna layouts
Impedance controlled routing
50Ω controlled impedance traces
High speed signal routing
RF signal integrity optimization
Transmission line routing
Ground plane and power integrity planning
EMI/EMC conscious board layouts
Bluetooth, WiFi, LoRa, GPS, and wireless products
ESP32 RF board layouts
RF module integration
SMA, U.FL, and RF connector integration
2 layer, 4 layer, and multilayer boards
Manufacturing ready files for JLCPCB, PCBWay, and other fabricators
Gerber, drill, BOM, pick and place, and production files
I work with KiCad, Altium Designer, and EasyEDA, delivering clean, manufacturable layouts based on your requirements.
Message me with your schematic, specifications, or project details, and lets build your RF PCB.
