I will do rapid solidworks 3d cad modeling and technical drawings for manufacturing
Youssef Nasr
Level 2
About this gig
Have a sketch, a photo, an old part or just an idea? I'll turn it into an accurate SOLIDWORKS 3D model and a technical drawing your machine shop can build from.
I'm a CSWP & CSWP Sheet Metal certified R&D Mechanical Design Engineer with 25+ delivered projects and a 5.0 rating.
WHAT YOU CAN SEND ME
- Hand sketch, photo or PDF/DWG drawing
- A real part with measurements
- STEP / IGES / STL file to fix or redraw
WHAT YOU GET
- Clean, fully editable SOLIDWORKS model (SLDPRT / SLDASM)
- STEP, IGES, DXF or STL for CNC, laser cutting or 3D printing
- Dimensioned PDF drawings with tolerances, GD&T, section views and title block (ISO or ANSI)
- Assembly drawing with BOM and exploded view (Premium)
GOOD FOR
CNC milling & turning - laser/plasma cutting - sheet metal - 3D printing - plastic parts
WHY ME
- Engineer, not just a modeler: I check that your part can actually be made (DFM)
- Replies usually within 1 hour
- On-time delivery, clear communication
Need FEA, a render or a bigger assembly? Message me for a custom offer.
Note: I deliver digital files only, no physical manufacturing.
Delivery style preference
Please inform the freelancer of any preferences or concerns regarding the use of AI tools in the completion and/or delivery of your order.
Get to know Youssef Nasr
Youssef Nasr
R,D Mechanical Design Engineer, CAD Design, GYM, SOLIDWORKS
Level 2
- FromEgypt
- Member sinceNov 2024
- Avg. response time1 hour
- Last delivery3 weeks
Languages
English, Arabic
Hi, I’m Youssef Nasr, a passionate CAD engineer with expertise in 3D modeling, mechanical design, and product development. I am certified as a SOLIDWORKS Associate (CSWA) and Professional (CSWP), which ensures my ability to create precise, efficient, and professional designs tailored to meet your project needs.
I specialize in turning concepts into detailed 3D models, optimizing designs for manufacturing, and delivering innovative solutions for mechanical and product design challenges. Whether you need assistance with prototyping, assembly design, or custom part creation, I am here to help!
My Portfolio
Other Industrial & Product Design Services I Offer
FAQ
Can you model from a hand sketch or a photo?
Yes. A sketch with the main dimensions is ideal. With a photo, include at least one known measurement so I can scale it accurately.
What if I don't have dimensions?
Send a photo with a ruler or a known size next to the part. I'll estimate the rest and confirm the key sizes with you before I finalize.
Which files will I receive?
Native SOLIDWORKS files (SLDPRT/SLDASM) plus STEP and PDF drawings. Standard adds IGES and DXF, and Premium includes every format you need.
Do your drawings include tolerances and GD&T?
Yes. Drawings follow ISO or ANSI with general tolerances, and GD&T is added where the function needs it (Standard and Premium).
Can you do sheet metal parts?
Yes. I'm CSWP Sheet Metal certified and can deliver bend-ready models plus flat-pattern DXF files for laser cutting.
Do you manufacture the part?
No. I deliver digital files only, ready for your machine shop, laser cutter or 3D printer.
